di-soric LAT45-6MIU-B5
- Operating principle:
- Optical
- Design:
- Cuboid
- Detection range:
- 300 … 6000 mm
- Switching output:
- pnp (2x), 200 mA, NO/NC, konfigurierbar
- Light source:
- Laser
- Supply voltage:
- 18 … 30 V DC (Supply Class 2)
- Connection:
- Connector, M12
Price and availability on request
Not sure which model fits?
A technical contact will review your application and recommend the right configuration.
Have your application reviewedDescription
The LAT-45 impresses with a long range of up to 10 m. The sensor is equally suited to measuring and switching applications. The LAT-45 is operated either via the keypad or IO-Link, and its easy-to-read display shows the measured values. Good independence from color and surface allows distance measurement on many surfaces.
- IO-Link
- Long range
- Good independence from color and surface
- Red laser for easy alignment
- Measured value shown on the display
- Easy operation
- Rugged metal housing
Technical data
| Part number | LAT45-6MIU-B5 |
|---|---|
| Operating principle | Optical |
| Supply voltage | 18 … 30 V DC (Supply Class 2) |
| Idle current (max.) | 150 mA |
| Housing length | 52 mm |
| Housing material | Die-cast zinc (black, painted) |
| Weight | 309 g |
| Protection class (electrical) | III, Operation on safety extra-low voltage |
| Design | Cuboid |
| Switching output | pnp (2x), 200 mA, NO/NC, konfigurierbar |
| Switching function | Normally open (NO), Normally closed (NC) |
| Interface | IO-Link V1.1, COM2, Smart Sensor Profile |
| Light source | Laser |
| Detection range | 300 … 6000 mm (90 % reflectance) |
| Indicator | LED green - Status, yellow - switching output |
| Switching frequency | 0.3 Hz … 11 Hz |
| Operating temperature | -10 … +60 °C |
| Ingress protection | IP67 |
| Connection | Connector, M12, 5-pin |
