HIKROBOT Code-Leser MV-ID5050XM-00C-NNN
HikRobot Code-Leser MV-ID5050XM-00C-NNN ist ein Code-Leser von HikRobot (MV-ID5050XM-00C-NNN).
Preis und Verfügbarkeit auf Anfrage
Unsicher bei der Auswahl?
Ein technischer Ansprechpartner prüft Ihre Anwendung und empfiehlt die passende Konfiguration.
Anwendung prüfen lassenBeschreibung
Key Feature
- Adopts built-in deep learning algorithm to read codes with good robustness.
- Adopts a built-in touchscreen to view the statistical data and adjust parameters via pressing on the screen.
- Adopts multiple indicators to show device status from different sides.
- Rotatable cable design for flexible mounting.
- Adopts controllable light source design to provide diversified light according to workpiece material.
- Adopts I/O interfaces for input and output signals.
- Supports high-precision sensors to get the installation position.
- Supports broad selection of accessories, such as multi-color light source or wafer light source, for improving code-reading ability and scene adaptability.
- Supports HDR function to provide high-contrast image.
- Provides multiple lens mounts, such as C-mount lens, mechanical focus lens, or liquid focus lens.
- The device with multi-color light source supports red/green/blue/white light source, and you can switch the light source.
Technische Daten
| Artikelnummer | MV-ID5050XM-00C-NNN |
|---|---|
| Typ | MV-ID5050XM-00C-NNN |
| Codearten | 1D codes: Code 39, Code 93, Code 128 (GS1-128 included), CodaBar, EAN 8, EAN 13, UPCA, UPCE, ITF 14, ITF 25, Matrix 25, MSI, China Post, Code 11, Industrial 2of5, and Pharmacode 2D matrix codes: QR Code (GS1-QR included), Data Matrix (GS1-DM included), MicroQR, AZTEC, HanXin 2D stacked codes: PDF417, MicroPDF417 |
| Max. Bildrate | 92 fps |
| Max. Lesegeschwindigkeit | 120 codes/sec |
| Sensortyp | CMOS, global shutter |
| Pixelgröße | 3.45 μm × 3.45 μm |
| Sensorgröße | 1/1.45" |
| Auflösung | 2432 × 2048 |
| Belichtungszeit | 38 μs to 1 s |
| Gain (Verstärkung) | 0 dB to 37 dB |
| Mono/Farbe | Mono |
| Schnittstelle | Gigabit Ethernet (1000 Mbit/s) |
| Kommunikationsprotokoll | SmartSDK, TCP Client, TCP Server, Serial, FTP, Profinet, Ethernet/IP, MELSEC/SLMP, ModBus, Fins, UDP |
| Digital-I/O | 12-pin M12 connector provides power and I/O, including opto-isolated input (LineIn 0/1/2) × 3, opto-isolated output (LineOut 3/4/5) × 3, RS-232 input × 1, and RS-232 output × 1. Supports device triggering via pressing button on device and smart tune. |
| Stromversorgung | 24 ± 10% VDC |
| Leistungsaufnahme | Avg.: 8 W @ 24 VDC Max.: 14.4 W @ 24 VDC |
| Brennweite | / |
| Objektivanschluss | C-mount |
| Objektivdeckel | Transparent lens cap |
| Lichtquelle | No built-in light source |
| Anzeige | Power indicator (PWR), network indicator (LNK), and user-defined indicator (U1/U2) |
| Gehäusematerial | Metal |
| Abmessungen | Straight angle: 112.3 mm × 54 mm × 110 mm (4.4" × 2.1" × 4.3") Right angle: 88.7 mm × 54 mm × 132.4 mm (3.5" × 2.1" × 5.2") |
| Gewicht | Approx. 370 g (0.8 lb.) |
| Schutzklasse | IP67 (under proper installation of waterproof lens cap) |
| Temperatur | Working temperature: 0 °C to 50 °C (32 °F to 122 °F) Storage temperature: –30 °C to 70 °C (–22 °F to 158 °F) |
| Luftfeuchtigkeit | 20% RH to 95% RH (no condensation) |
| Vibrationsfestigkeit | Device only: 10 Hz to 55 Hz, 1.5 mm full amplitude, 2 hours per axis (X/Y/Z) (IEC 60068-2-6:2007\GB/T 2423.10-2019) |
| Schockfestigkeit | Device only, 30 g / 11 ms, half-sine wave, 500 shocks per axis (6 directions) (IEC 60068-2-27\GB/T 2423.5-2019) |
| Software | IDMVS |
| Zertifizierung | CE, RoHS, KC |
